| Features |
- Hand-tightens-no tools required
|
- Tapered neoprene bushing and O-ring seal out moisture and dirt ingress.
|
- Corrosion-resistant, non-magnetic aluminum construction
|
- Chuck grip provides high mechanical pull-out performance which exceeds applicable requirements.
|
|
| Application |
- Silver Grip® Tray/Cord fitting is the safe and cost effective choice for increased safety when terminating portable cord and try cable in hazardous locations. Designed for use in Class I, Gas and Vapor environments, the Silver Grip® Tray/Cord fitting provides efficent strain relief for cables entering enclosure and raceways, and for cords used on portable equipment.
|
|
| General |
Material |
Aluminum |
|
| Dimension Information |
Hub Size (inches) |
1/2 |
Cable Opening-Minimum (inches) |
0.250 |
Cable Opening-Maximum (inches) |
0.400 |
Throat Diameter (inches) |
0.540 |
|
| Packaging |
Outer Package |
25 |
Package Height |
3.5 |
Package Length |
7.62 |
Package Width |
6.62 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
15 lbs. per 100 |
|
| Notes |
*Note |
Tray cable is not suitable for use in Zone 1 locations. Portable cord can be used in Zone 1 applications only when installed on portable equipment. |
|
| Certifications |
RoHS Compliance |
Yes Generate Compliance Certificate |
