| Features |
- Extra wide 3 3/4" opening provides more hand space for easy access to the wiring chamber.
|
- Precision cast and machiined surfaces permit safer wire pulling.
|
- Precision NPT threaded hubs allow trouble-free field installation for rigid or IMC conduit.
|
|
| Application |
- Junction for branch conduits in hazardous locations.
|
|
| General |
Material |
Aluminum |
Volume (cu.in.) |
31 |
|
| Dimension Information |
Hub Size (inches) |
3/4 |
Dimension A (inches) |
4 5/8 |
Dimension B (inches) |
2 3/8 |
Dimension C (inches) |
3 3/8 |
Dimension D (inches) |
2 3/16 |
Dimension E (inches) |
1 3/16 |
Dimension F (inches) |
1/2 |
Dimension G (inches) |
3/4 |
Dimension H (inches) |
4 |
Dimension J (inches) |
2 5/8 |
|
| Packaging |
Inner Package |
1 |
Outer Package |
5 |
Package Height |
6.5 |
Package Length |
23.06 |
Package Width |
6.12 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
2.92 lbs. Each |
|
| Notes |
*Note |
Class I, Div. 1&2, Groups C, D - Explosionproof |
**Note |
Class II, Div. 1, Groups E, F, G - Dust-Ignitionproof |
***Note |
Class III, Div. 1&2 - Raintight |
****Note |
NEMA 3, 4, 7 CD, 9 EFG - Wet Locations |
|
| Certifications |
RoHS Compliance |
No |
